£892.21
C20XE 2.0 16v Flat top Forged Piston Kit.
Manufacturer kit reference: K9396
| Engine Code | C20XE |
|---|---|
| YOM From | 1993 |
| YOM To | 1998 |
| Bore Size | 87.5mm |
| Stroke | 86mm |
| Compression Height | 30.5mm |
| OEM Comp Ratio | 10.5:1 |
| Number of Rings | 3 |
| OEM Rod Length | 143mm |
| Clip Part Number | CW21 |
| Pin Size | 21mm |
| Pin Part Number | WP051 |
| Cylinders | 4 |
| Valves Per Cylinder | 4 |
| Suits Wossner Con Rod | G0033 |
| Con Rod Length C/C | 143.1mm |
| Piston reference | Piston diameter | Compression ratio | Capacity |
|---|---|---|---|
| K9396D150 | 87.43mm | 11:1 | 2068cc |
Piston diameter and cylinder bore are different measurements. Select the correct size and confirm the engine specification before ordering.
