£849.43
Lancer 2.0 16v Turbo EVO X RS Race Comp Stroker Forged Piston Kit.
Manufacturer kit reference: K9498
| Engine Code | 4B11 MIVEC |
|---|---|
| YOM From | 2008 |
| YOM To | 2015 |
| Bore Size | 86mm – K9498DA |
| Stroke | 98mm |
| Compression Height | 27.36mm |
| OEM Comp Ratio | 09:01 |
| Number of Rings | 3 |
| OEM Rod Length | 143.75mm |
| Clip Part Number | CW23 |
| Pin Size | 23mm |
| Pin Part Number | WP094 |
| Cylinders | 4 |
| Valves Per Cylinder | 4 |
| Piston reference | Piston diameter | Compression ratio | Capacity |
|---|---|---|---|
| K9498DA | 85.92mm | 9.0:1 | 1998cc |
Piston diameter and cylinder bore are different measurements. Select the correct size and confirm the engine specification before ordering.
