£705.60
Prelude Si H23 9:1 Comp Forged Piston Kit.
Manufacturer kit reference: K9497
| Engine Code | H23A2 |
|---|---|
| YOM From | 1992 |
| YOM To | 1996 |
| Bore Size | K9497D050 |
| Stroke | 95mm |
| Compression Height | 30.58mm |
| OEM Comp Ratio | 10:01 |
| Number of Rings | 3 |
| OEM Rod Length | 141.5mm |
| Clip Part Number | CW22 |
| Pin Size | 22mm |
| Pin Part Number | WP136-SP |
| Cylinders | 4 |
| Valves Per Cylinder | 4 |
| Piston reference | Piston diameter | Compression ratio | Capacity |
|---|---|---|---|
| K9497D050 | 87.44mm | 9.0:1 | 2283cc |
Piston diameter and cylinder bore are different measurements. Select the correct size and confirm the engine specification before ordering.
