Deatschwerks

DeatschWerks Set Of 4 Injectors 0850cc/Min

matched set of 4 injectors 850cc/min

Fuel Pressure Range 40-90 psi
Minimum Pulse Width 1.1 ms
Maximum Duty Cycle 91%
Coil Impedance 12.2 ohm
Injector Type Denso Top Feed
Connector Type Sumitomo



Nominal Static Flow Rate



PSI > 43 58 70 80 90 100
cc/min 863 982 1112 1192 1268 1390
lb/hr 82.2 93.5 105.9 113.5 120.8 132.4



Please note: Flow rates listed are the nominal (normal minimum) rates for this injector part number. All sets are flow balanced. For actual flow rates of your set, please refer to the flow report that will accompany your order.



Offset In Milliseconds (Pressure Vs Voltage)



PSI >
VOLTS v
43 58 70 80 90 100
8 2.00 2.34 2.97 4.16 8.00 8.00
9 1.56 1.70 1.96 2.43 3.94 8.00
10 1.23 1.28 1.58 1.78 2.21 8.00
11 0.99 1.11 1.31 1.45 1.67 2.16
12 0.85 0.96 1.17 1.23 1.33 1.75
13 0.71 0.76 0.93 1.04 1.17 1.52
14 0.59 0.65 0.82 0.90 1.04 1.33
15 0.49 0.61 0.67 0.74 0.80 1.14
16 0.36 0.48 0.60 0.69 0.77 1.04
