Wossner Fiat 500 Abarth 1.4 Turbo H-Beam Connecting rod kit (K0308)

Wossner Pistons

Wossner Fiat 500 Abarth 1.4 Turbo H-Beam Connecting rod kit (K0308)

£636.94

Fiat 500 Abarth 1.4 Turbo H-Beam Connecting rod kit.

Manufacturer kit reference: K0308

Fiat 500 Abarth 1.4 Turbo H-Beam Connecting rods

Engine Code	312A
YOM From	2008
YOM To	2016
Con Rod Length C/C	129mm
Con Rod Big End Dia	45.13mm
Con Rod Big End Width	21.7mm
Con Rod Small End Dia	18mm
Con Rod Small End Width	15.5mm
Con Rod Bolt	5/16"

Kit contents

Fiat 500 Abarth 1.4 Turbo H-Beam Connecting rods
ARP Bolt 5/16" Thread 1.5" UHL 2000 Series ( 3AG1.505-2U) × 8
ARP Assembly Lubricant (100-9908)

Installation: Additional engine-block machining is required to provide clearance.
